SPECIFICATION

MODEL		SK-MAN 2000		SK-MAN 6000
HOISTING STROKE		2000 MM		5000 MM
HOISTING SPEED		1830 MM/MIN		1993 MM/MIN
BOOM STROKE		2000 MM		6000 MM
BOOM SPEED		MAX. 2260 MM/MIN		MAX. 2015 MM/MIN
COLUMN ROTATION ANGLE		± 180˚		± 180˚
COLUMN ROTATION METHOD		MANUAL		MANUAL
전원		380V X 60HZ X 3PH		380V X 60HZ X 3PH
HOIST PART	MOTOR	AC 0.4KW X 4P B/K		AC 1.5KW X 4P B/K
	REDUCER	SI - U80L - 1/60		DWBM135-A-1/200
	FEEDING	TIMING PULLEY	14L 075-6F	SPUR GEAR	28Z/94Z
		TIMING PULLEY	60L 075-6W	SPROCKET	RS120x20T
		TIMING BELT	337L 075	SPROCKET	RS120x10T
		SPROCKET	#RS60 X 14NT	CHAIN	RS #120-2열
CROSS HEAD PART	MOTOR	AC 0.4KW		AC 0.75KW
	REDUCER	SI - S60R - 1/60		DWBM120-A-1/300
	FEEDING	PINION GEAR	2.5M X 21NT	PINION GEAR	M5x22Z
		TIMING PULLEY	34L 075-6	RACK GEAR	ESFR5-7500
		TIMING PULLEY	16L 075-6F	X-AXIS	DKM9WD 30BLx90W
		TIMING BELT	270L 075	Z-AXIS	DKM9WD 30BLx90W
